Description
Description:
- Horsepower and Torque: 610 Horsepower / 525 FT. LBS. Torque
- Cylinder Heads: Gen III Hemi Apache Aluminum Cylinder Heads
- Compression Ratio: 10.48:1
- Pistons: Forged
Block:
- Engine Manufactured and Machined in the USA!
- NEW “BGE” Hellcat Engine Block
- 4-Bolt Main
- 4.090″ Bore
- 1-Piece Rear Main Seal
Rotating Assembly:
- Forged Steel Crank
- 4.050″ Stroke
- 6.125″ Connecting Rods
- Forged Pistons
- Internally Balanced Front and Rear
Cylinder Heads:
- Gen III Hemi Apache Aluminum Cylinder Heads
- 73cc Chamber
- 2.140″ Intake / 1.650″ Exhaust Valves
- Can Accept 6.1, 6.4 or 2009+ 5.47L Intake Manifolds
- Does Not Accept 2008 or Older 5.7L Intakes
- Not Tapped for Stock Hellcat Supercharger. Bolt Pattern Differs from N/A Intake
Cam Specs:
- Hydraulic Roller Cam
- .614 Intake / .614 Exhaust Lift
- 231 Intake / 255 Exhaust Duration
- @.050-115 Degree Lobe Separation
Ignition Timing:
- Controlled by ECU
Also Includes:
- Fuel Injection
- Throttle Body
- Harmonic Balancer
- Fabricated Intake Manifold
- Muscle Car Style – Mid Sump Oil Pan
- Coils
- Timing Cover (Car)
- Valve Covers
- Water Pump
- Holley Terminator ECU Controller Kit and Wiring Harness
Notes:
- Features 2013+ 58X reluctor wheel
- 2009+ crankshaft spacing
- 2009+ car timing cover
- VVT locked out
- MDS – eliminated
