Description
Description:
- Horsepower & Torque: 500 Horsepower / 510 ft. lbs. Torque
- Compression Ratio: 10.3:1
- BluePrint Engines Aluminum Heads
- BluePrint Engines Hydraulic Roller Cam
- BluePrint Engines Forged Crank
- BluePrint Engines Forged Pistons
Block:
- BluePrint Engines High Strength Cast Iron Block
- Manufactured and Machined in the USA!
- Drilled and Tapped for Clutch Linkage
- Mech Fuel Pump Provision: Yes
- Passenger Side Dipstick
- 1-Piece Rear Main Seal
- 4-Bolt Main
- 4.125″ Bore
Rotating Assembly:
- BluePrint Forged Steel Crankshaft
- 3.750″ Stroke
- 5.700″ Connecting Rods w/ 150,000 PSI Bolts
- Forged Pistons
- Internally Balanced Front / Externally Balanced Rear
Cylinder Heads:
- BluePrint Aluminum Cylinder Heads – HP8103
- 64cc Chamber
- 2.08″ Intake /1.60″ Exhaust Valves
- 220cc Intake / 67cc Exhaust Runners
Cam Specs:
- Hydraulic Roller
- .553 Intake / .576 Exhaust Lift
- 236 Intake / 242 Exhaust Duration
- @ .050-110 Degree Lobe Separation
Ignition Timing:
- 10-16° Initial and Total Timing 32-34° at 3500 RPM
Also Includes:
- Holley 850cfm Double Pumper Carburetor – BPP04781S
- Satin Aluminum Intake Manifold – BPP350VINT
- HEI Ready Run Distributor – BPP350RBK
- Valve Covers – BPP9518
- Timing Cover
- Oil Pan
Notes:
- Not for EGR
- The Aftermarket intake manifold installed on this engine may not be compatible with OEM accessory brackets that use intake mounted bosses.
- The performance aluminum cylinder heads on this engine feature a .500 raised port vs OEM.
