Description
Honda GX120 QXS2 / GX120UT2QXS2 Horizontal OHV Engine, 120cc, 3.5 Net HP, 3/4-inch x 2-7/16-inch Crankshaft, 12V/50 Watt Lamp Coil
Key Specifications
| BRAND | Honda |
|---|---|
| MODEL NUMBER | GX120-QXS2 |
| WARRANTY | 3 Year Consumer & Commercial |
| SHIPPING WEIGHT | 37 |
| DISPLACEMENT | 118cc |
| STARTER TYPE | Recoil |
| CRANKSHAFT ORIENTATION | Horizontal |
| CRANKSHAFT TYPE | Straight |
| FUEL SYSTEM | Gasoline |
| GEAR REDUCTION | No |
| CRANKSHAFT DIMENSIONS | 3/4″ x 2-27/64″ |
| CRANKSHAFT DIAMETER | 3/4″ |
| CRANKSHAFT LENGTH | 2-27/64″ |
| CRANKSHAFT ROTATION DIRECTION (FROM PTO SIDE) | Counterclockwise |
| CYLINDERS | 1 |
| CYLINDER BORE TYPE | Cast Iron |
| AIR CLEANER TYPE | Dual Element |
| OIL CAPACITY | 19 |
| LOW OIL SHUTDOWN | Yes |
| IGNITION SYSTEM | Transistorized Magneto |
| CARBURETOR TYPE | Float |
| CHOKE CONTROL | Manual |
| NOTES | Engine Notes: |
| PTO HEIGHT | 4 – 11/64 |
